Risk Management in trading systems

One of my first memories of learning market mechanics was a cover article of an issue of “Technical Analysis of Stocks and Commodities” that detailed some aspects of risk. I had never explored the subject, and was surprised by what was entailed. It was a typical instance of “you don’t know what you don’t know.”

I saved that issue of the magazine for many years. Unfortunately it was tossed somewhere along the way. But while reading that article I began to think about how software could help the retail trader. If a spreadsheet could take in the necessary information, the user could see where adjustments may need to be made to match their risk profile.

Thinking back at such a naive thought causes nostalgia. Those that know they need it have built it, those that do not know will either flame out or learn.

I recently purchased several audio books in the Jack Schwager series. I’ve read many of them, but it is nice to have them in audio form and listen passively. Certain nuggets stand out. In his hedge fund series of interviews, he goes back in history to the origins of the true “hedged fund”. From that it becomes clear that a risk management strategy is the core to generating alpha over the long haul. Studying additional materials on those first forays into “group investing” you see that it took a long time to catch on, but is a pillar of just about everything on Wall Street.

But how much of that trickles down into the typical trading systems I am asked to build? Unfortunately, very little. Most are concerned with concentrated “bets” on the short-term direction of a security. Getting the entry and exit right and following the rules is certainly a big part of the equation. But ignoring the “bigger picture” items such as risk management is often the cause of big losses.

So what can I, the lowly software guy do? While I can sometimes draw their attention to the issue at the outset, often it comes down to reporting. After running a back test, provide some statistical references to a broader index, or VAR, or what the market was doing while the simulation was running. Those are small numbers that open the door to bigger discussions on what markets best match a particular strategy.

This is a deep subject. Perhaps I should break it down into smaller sections by risk type to organize it better.

Please note: I am not pretending to be an expert here. I am simply writing down what I know for my own benefit. If you want to chime in, by all means, please do!

The CQG API and cqg_helper

Just as I have done for Interactive Brokers, I am also sometimes asked to build interfaces to CQG. While it is not as developed as Interactive Brokers, I have decided to offer what I have to the open source community. This repository will get you started on the path to communicating to CQG via their WebAPI interface using C++. Enjoy.

And please feel free to add issues and pull requests. Be part of the open source community!

The Interactive Brokers API and ib_helper

I often build trading systems for users of Interactive Brokers. Rather than build the common utilities over and over, I have developed a small “toolbox” that contains what I often need. I have decided to make this toolbox available to the open source community (MIT licensed), in the hopes that others may decide to contribute.

This library has two main purposes:

  • Provide simple interfaces for the simple things. This lessens the need to implement EWrapper functions that do not apply, but categorizes them for easy implementation.
  • Provide a testing framework. Google Test is used to build tests, and a “Mock” connector mimics IB TWS to allow for building unit and integration tests. With little effort, you could even build backtests of strategies.

Please check it out. Feel free to add issues and pull requests. Enjoy!

Attention Traders: the odds are against you…

… let me help.

Trading is hard, especially for the retail trader. To put it bluntly, large institutions will always have the advantage. While there are many mountains to overcome, I am attempting to help myself and others with some of the more technical hurdles that us retail traders confront.

One of the biggest challenges is speed of execution. Without some large changes in the industry, retail traders will never have the resources to connect directly to the data feeds and other systems necessary to complete a trade. While we can’t shave of the last few milliseconds, we can greatly reduce the tick-to-trade time by improving our front ends.

I have for years worked with Interactive Brokers as my broker. While all brokers have their warts, Interactive Brokers has provided me with relatively painless access to the markets. And while their Trader Workstation software is unwieldy, it is fairly complete. But partly due to all those features that were asked for by traders, the application is not as fast as it could be.

Part of the problem is that it is a Java application. It is simply not the right choice for a data heavy, performant application. It is obvious they have worked hard tuning it. To be honest I am surprised it is as fast as it is. But it is still too slow.

Rewriting Trader Workstation would be great. But who is going to do it? I would love to. Perhaps some decade I will. But that is simply too big of a project to bite off in one chunk. So instead, we will eat this elephant in smaller chunks.

I am completing a simple application I like to call “Sniper”. It follows me as I click around looking at different stocks and futures in Trader Workstation. When I want to enter an order, I can click around in Trader Workstation to build my order (yuck) , or I can hit a hotkey while Sniper is active and have the order placed immediately.

Now, you could configure hotkeys in Trader Workstation. Let me know when you figure out the intricacies of that. Instead of fighting the myriad of hotkey options in Trader Workstation, simply install Sniper. Sniper connects via the Interactive Brokers API. It provides hotkeys to place limit orders that can immediately be transmitted to Interactive Brokers for execution.

I am donating this small utility to entice you to talk to me about other software that will make your trades easier and faster.

Sniper will be available for Linux, MacOS and Windows. This post will be updated with more information as the product is released. The goal is to have version 1.0 released around April 15, 2023.

Almost bare metal Part II

In my previous post I mentioned I have been working on moving a routine that handles many hashing tasks at once to the GPU. The preliminary results are encouraging, although I cannot say they are apples-to-apples to the actual task at hand.

To get some simple numbers, I simplified the task. There is a stream of bytes that must be hashed using the SHA256 algorithm. The stream of bytes includes a part that is somewhat static and a part that changes. The part that changes could be one of about 13,000 combinations. The task is to hash those 13,000 byte streams and check which (if any) have the value below a certain threshold, similar to the process used by Bitcoin to publish blocks.

Because we are now dealing with moving blocks of memory across a bus, the actual process was adjusted to do this in more of a “batch” mode. The 13,000 byte streams are easily created on the CPU. Each byte stream is put in an array (also on the CPU).

Now for the fun part. The entire array is hashed one element at a time. The results are placed in another array. This is done once on the CPU and once on the GPU, with the timing results compared.

The initial results were not good:

Building CPU IDs: 3345344ns total, average : 261ns.
Building GPU IDs: 142561855ns total, average : 11137ns.

But running it a second time yielded:

Building CPU IDs: 3297128ns total, average : 257ns.
Building GPU IDs: 795204ns total, average : 62ns.

And a third run yielded:

Building CPU IDs: 3304968ns total, average : 258ns.
Building GPU IDs: 788838ns total, average : 61ns.

I would guess that the first run had to set up some things on the GPU that cost time. Subsequent runs are much more efficient. To support that thesis, note that the time it took the CPU was fairly consistent across all three runs, and the GPU runs after the initial run were also very consistent.

Runs beyond the first 3 show consistent times on both CPU and GPU.

The synopsis is: Bulk hashing on a NVidia GeForce 2060 (notebook version) using SYCL provides about a 4X improvement in hashing. Moving to CUDA provides similar results, so it seems the language does not seem to matter here.

More questions to be answered:

  • Comparing the hashes to a “difficulty” level must also be done. Would the GPU be more efficient here as well? Should it be done in the same process (memory efficient) or in a separate process (perhaps pipe efficient)?
  • What would happen if we ran this on an AMD GPU with similar specifications?
  • What resources were used on the GPU? Are we only using a fraction of memory/processing abilities, or are we almost maxed out?
  • At what point is the arrays that are passed in or retrieved from the card too big to handle?

(Almost) bare metal

I love writing in C++. The reasons are performance (I am a speed junkie) and learning opportunities. If necessary, I can tune a routine to seek out the fastest way to achieve the result. Each time I do, I learn a lot. I have been learning constantly since I picked up the book on BASIC that I received with my Timex-Sinclair 1500.

But what if my computer is simply not fast enough to perform the routine I need it to? If the task can be broken into smaller, somewhat independent pieces, we can use threading. My machine has 8 CPUs and 16 cores. My latest project included a process that took 20 seconds on 1 thread, and 6 seconds with 16 threads. And it wasn’t that hard to do.

But 6 seconds is not fast enough. And during those 6 seconds my CPUs are pegged at 100%. The routine is tuned to the best of my ability. What now? Well, the process is some number crunching. I have a video card that loves to crunch numbers. What will it take?

I have coded the routine in CUDA as well as SYCL and will have some results soon (Update: See Part II). I do not get to do this stuff often, so I am enjoying re-learning CUDA and this is my first round with SYCL. SYCL looks like a winner here, as I will be able to compare results between some NVIDIA and AMD cards with (hopefully) the same codebase.

But using GPUs are not the only option for such tasks. There are ASICs available for my current number-crunching necessity. And as I walked down the ASIC road I was able to explore another avenue that I had only glossed over in some prior projects: FPGAs.

ASICS are purpose-built microprocessors. They are designed to be fed a certain way, and spit out the answer in a certain way. You can think of it as getting a new gadget that has the sticker “no user serviceable parts inside”. You cannot get that chip to do anything beyond what it was meant to do.

FPGAs are in the middle between microprocessors and ASICs. In fact, you can use an FPGA as a way to prototype an ASIC. But here, we are not talking making it do what we want by manipulating C or C++. We are talking about manipulating transistors and wires. It is digital circuit building without the breadboard and soldering iron (well, at least in some cases).

FPGAs have been around for a while. But until fairly recently they were simply too expensive for anything but the big budget projects. Think government, Wall Street, Google, and Amazon. Today, you can experiment with an FPGA for $40 or less.

As a software developer, I had to twist my brain to begin to reason about how get these things to do what I want. I have done some microprocessor work. I have written software for embedded devices. I know what a transistor is and when to use a NAND. But FPGAs are requiring me to rewire my brain as I rewire that chip.

Where To Begin

I am just getting started. So here is what I have learned so far. The big hardware players in this arena are Xilinx (now owned by AMD), Altera (now owned by Intel) and Lattice. There are other players, but for what I am doing and where I am at in my exploration, I want to examine these suppliers before getting into the nuanced specifics. I am at the “I don’t know what I don’t know” stage.

When digging through the interwebs, there are a number of development boards and chips that keep popping up. So if you want to follow the tutorials, you will need to get your hands on some hardware. My first board will not be the latest and greatest (one I looked at on Mouser was just over USD$17,000.00). It will be modest and with a manufacturer that seems to often be used in the industry I am working with. Here are the 2 I am looking at:

The Digilent Basys 3

This is often used in FPGA tutorials. The development board includes a good amount of toys to play with to build your knowledge. Pushbuttons, LEDs, Ethernet port, etc. for around US$160

The Digilent Arty A7/S7

This also appears in some tutorials. The S7 seems to be the low-cost version of the A7. Both come in two flavors, so 4 different chips for 4 different prices. The A7 includes an Ethernet port, whereas the S7 does not. The A7 with the lower cost chip is around $160

Honorable Mentions

If you are looking to get into FPGA on the cheap, check out the Lattice Icestick. But don’t stop there. There are plenty of others with varying sizes of “maker” communities around them.

Debugging in VI

I switched back from Visual Studio Code to vi (I tire of switching from keyboard to mouse). As my memory is not very good, here is my cheat-sheet for using :Termdebug

Starting a debug session: Termdebug [executable_name]

Navigating the 3 windows: CTRL + w and then j or k.

Set / remove a breakpoint: :Break :Clear

Step / Next: s or n

Run / Continue: run or c

Pros and Cons of Centralization

One of the subjects that many in the crypto universe speak of is centralization. Most speak of it as something that must be destroyed. But it does provide services. Here are my thoughts:

Pros of Centralization

I have several bank and investment accounts. The majority of them are insured by either FDIC or SIPC. While the US government does not explicitly say they back these insurance institutions, these are (IMO) truly “too big to fail”.

That means that the cash I have deposited is “mostly” secure against the bank failing. The (very) small percentage chance that the FDIC or SIPC fails is small enough that I do not worry about it. Should they fail, the world will have bigger problems than money.

Another pro is security. We rely on the fact that banks know how to secure the deposited funds. They take on the risk of the funds I deposit. The bank will fail if the risks they take fail. So they put guards in place to prevent their own failure. They are basically in the business of protecting my money so they can make money with it.

You can say “that is not fair. They are charging a much higher percentage interest than what they are paying me.” True. But if you think you can do better, check out the real returns of some of the P2P lending platforms out there. I believe you will find that the due diligence of a risk-averse lender can easily be a full-time job.

To me, the biggest benefit is the lack of threat of robbery. If I kept all my money in my home, someone is eventually going to know about it. That opens me up to a physical threat of someone taking it. I realize someone can always attempt a robbery, regardless of if they know I store money there. But should they learn that I keep all my money there greatly increases the risk of me being robbed.

Also, contrary to the belief of many, the central bankers (a.k.a “The Fed” in the US) do perform a vital service. They have powerful tools at their disposal to manipulate the market. Without those tools, the US economy would have completely failed many times over. So, preventing crashes is a good thing, right? Well…

Cons of centralization

I am not advocating that crypto is worthless because the banks perform a service. I believe the technology is great. But there are some trends in crypto that remove the advantages of banks because they too are becoming more centralized. More on that a little later.

In the secular world, the “golden rule” changes to “he who hath the gold makes the rules.” And for societies that run on some form of money (in other words, practically all society), controlling the money supply puts power into the hands of few.

Throughout history, centralization of power has always lead to problems (the lack of centralization has also lead to problems, but I digress). Having money is an easy, powerful, and (often) legal form to control others. Centralization is not always bad, but it easily leads to abuse of power.

So we go back to The Fed. When they push buttons and pull levers to attempt to steer the US economy, their effects ripple through the world economy. Those bankers are not concerned about any economy other than the US economy. The US government is (arguably) concerned with world stability, but not The Fed. Remember, the decisions of The Fed are (arguably) not controlled by politicians. So while they may serve a purpose for the US, they affect the world. And the majority of the world is not their concern.

Concluding thoughts

I have many more thoughts on the matter. But the above forms the crux of what is right and wrong with crypto IMO.

Providing the security without the centralization is a near impossible task. When you have something someone wants, you risk having it taken by force. If it is a government you worry about, a decentralized cryptocurrency may be the answer. Just remember that at that point, you are now responsible for all the services that banks provide.

Do you want to get involved? Great! Do you not know where to start? Be careful! Remember, you are now your own bank. You need to protect your own money. Start small, learn carefully. Things will continue to move fast. But that does not mean you are forced to take unnecessary risks.

NodeContext in Bitcoin Core

<disclaimer> These notes are my understanding by looking at code. I may be wrong. Do not take my word for it, verify it yourself. Much of what is below is my opinion. As sometimes is the case, following good practices the wrong way can make a project worse. That is not what I’m talking about here.</disclaimer>

Recent versions (0.20ish) of Bitcoin Core attempt to reorganize logic into objects with somewhat related functionality. In my opinion, this is one of the best ways to reduce complexity. External components communicate with the object with well defined interface. This can lead to decoupling, which makes unintended side effects less likely.

I am focusing on the NodeContext object, as I believe this would be a big benefit for the Komodo core code. I am using this space for some notes on how Bitcoin Core broke up the object model. I hope this post will help remove some notes scribbled on paper on my desk. And who knows, it may be useful for someone else.

Breakdown of NodeContext

The NodeContext object acts as a container for many of the components needed by the bitcoin daemon. The majority of the objects are std::unique_ptr. This is a good choice, as copies are explicit. Below are the components within NodeContext:

  • addrman – Address Manager, keeps track of peer addresses
  • conman – Connection Manager – handles connections, banning, whitelists
  • mempool – Transaction mempool – transactions that as yet are not part of a block
  • fee_estimator
  • peerman – Peer manager, includes a task scheduler and processes messages
  • chainman – Chain Manager, manages chain state. References ibd, snapshot, and active (which is either the ibd or the snapshot)
  • banman – Ban manager
  • args – Configuration arguments
  • chain – The actual chain. This handles blocks, and has a reference to the mempool.
  • chain_clients – clients (i.e. a wallet) that need notification when the state of the chain changes.
  • wallet_client – A special client that can create wallet addresses
  • scheduler – helps handles tasks that should be delayed
  • rpc_interruption_point – A lambda that handles any incoming RPC calls while the daemon is in the process of shutting down.

One of the largest refactoring challenges in Komodo is the large number of global variables. Pushing them into their respective objects (especially chainmain and args objects) will help get rid of many of those globals. This will help compartmentalize code and make unit tests easier.

Crypto Currency Exchange Connector v2

I began a personal project a long time ago to provide connectivity to various cryptocurrency exchanges. I never got around to finishing it. It did however stay in my mind. And while working on other projects, I gathered knowledge of better ways to implement different pieces.

Recently I began anew. The market has changed a bit, but the basics still hold true. There is a need for fast connectivity to multiple exchanges. Open-source “one size fits all” solutions that I researched did not work for me. They did not focus on speed and efficiency.

The Problems

Centralized exchanges are still the norm, although distributed exchanges (i.e. Uniswap) are making headway. While I believe distributed exchanges will be tough to beat in the long term, currently their centralized cousins provide the “on ramps” for the majority of the casual users. They also suffer from a dependence on their underlying host (i.e. Ethereum in the case of Uniswap). These are not impossible hurdles to overcome, but for now centralized exchanges play a large role in the industry.

Regardless of the centralized/decentralized issue, there are multiple exchanges. Those with connectivity to many of them can seek out the best deals, as well as take advantage of arbitrage opportunities. But this is a crowded field. Getting your order in before someone else becomes more important as bigger players squeeze the once juicy profits of the early adopters.

The Solution

A library that knows how to keep a connection to a variety of exchanges and provides a platform to develop latency-sensitive trading algorithms is the problem that the Crypto Currency Exchange Connector is attempting to solve.

The library is being written in C++. It will be modular to support features such as persistence, risk management systems, and the FIX protocols. But the bare-bones system will get the information from the exchange and present it to the strategy as quickly as possible. It will also take orders generated by the strategy and pass it to the exchange as quickly as possible. A good amount of effort has been put forth to make those two things performant.

Giving strategies the information needed to make quick decisions was the focus. Keeping strategies from the need of “boiler plate” code was a secondary goal that I feel I accomplished.

Compiling in only the pieces necessary was another focus. I debated for a good bit about making each exchange a network service you can subscribe to. That makes sense for a number of reasons, but it is an extra latency that I did not want to pay for. And having everything compiled into one binary does not mean it is impossible to break it out later. I wrote it with the idea that off-loading exchanges to other processes or servers would be possible, but having it all-in-one is the default.

Persistence is another issue. There is a ton of data pouring out of the exchanges. Persisting it is possible. But having it in a format for research often requires dumps, massages, reformatting, and sucking it into your backtesting tool. To alleviate some of those steps, I chose TimescaleDB. It is based on Postgres, and seems to work very well. Dividing tick data into chunks of time can be done at export time. I have yet to connect it to R or anything like that, but I am excited to try. That will come later.

Project Status

I truly do not want this project to be set aside yet again. I have a strong desire to get this across the finish line. And it is very close to functional. There are only a few pieces left to write before my first strategy can go live.

I will not be making this project open source. It is too valuable to me, and gives me an edge over my competitors. At best I will take the knowledge I’ve gained and apply it to other systems that I am asked to build.
